2D Handheld Scanner
Description
Reviews
Function introduction
- New decoding chip to interpret various QR codes
- Plug and play, easy to set up, and can be used quickly with other office equipment
- Error rate as low as 1/5 million times, accurate and accurate
- with touch button
- Professional technology can scan WeChat, Alipay barcode
Product parameter
|
Model Number |
JAW-DS8608 |
|
Performance Parameters |
|
|
Light Sources |
630nm red LED |
|
Supported Symbologies
|
1D：UPC, EAN, Code128, AIM-128, ISSN, ISBN, Code39, Code39 Full ASCII, Code32, Code11, Code93, Matrix 2 of 5, Interleaved 2 of 5, Industrial 2 of 5, Codebar, MSI-Plessey, PLessey ITF-14, ITF-6, GS1-Databar(RSS). 2D：PDF417, Data Matrix ,QR Code, Hanxin. |
|
Scan Mode |
Automatic inductive |
|
Resolution |
3 mil (Code 39), 7.5 mil (Data Matrix), 4 mil (PDF 417) |
|
Field of View |
Horizontal: 46.1°; Vertical: 30.4° |
|
Optical System |
640pixels(H)*480pixel(V) |
|
Indicator |
LED, Speaker |
|
Interfaces |
USB HID/USB-COM/RS-232 |
|
Physical Parameters |
|
|
Dimensions |
96mm*108mm*150mm |
|
Weight |
315g |
|
Material |
ABS+PC |
|
Cable Length |
2M |
|
Environmental Parameters |
|
|
Operating Temperature |
0°C to 50 °C |
|
Storage Temp. |
-40℃~70℃ |
|
Relative Humidity |
0%~95% RH(non-condensing/non-freezing) |
|
Electrical Parameters |
|
|
Current |
DC5V±5% 350mA |
